Sealing joints and gaps is one of man's oldest craft activities. Today, silicone sealants are among the first choice and are indispensable in the construction industry and for DIY enthusiasts - whether for windows and doors, in the bathroom or the kitchen. This important material convinces with many special properties. Our Pilot® extender oils play an important role in this. You can find out exactly which ones in our article.
Silicone sealants have to fullfil a lot of requirements
Silicone sealants may be unremarkable, but their added value is enormous. Wherever joints, gaps and cracks between different materials need to be filled and sealed, silicone sealants offer a clean and durable solution. The variety of applications for both interior and exterior construction is high: in the sanitary area, the kitchen, for sealing doors, windows and window sills and much more. The sealant protects against dirt and moisture and, thanks to its permanently elastic properties, is ideally suited to withstand and compensate for building movements.
High requirement profile for silicone sealants:
- Curing on the spot due to atmospheric humidity
- Weather-resistant
- Water-repellent and waterproof
- UV- and temperature-resistant
- Corrosion-free (for application on metallic substrates)
- Resistant to ageing
- Good adhesion properties (can be applied to almost all substrates)
- Flexible and tear-resistant during application
- High insulating effect against electricity
Tailor-made Pilot® extender oils allow for high-quality silicone sealants
Silicone seals become perfect with low-viscosity base oils. These special products with narrow boiling points are used as so-called extender oils in silicone sealants. In order to meet the high requirements of the sealant, these extender oils must show high quality characteristics.
With its Pilot® extender oils, Haltermann Carless offers particularly high-quality products that optimally support the properties of silicone sealants.
Benefits of our Pilot® extender oils:
- Lowest aromatic content
- Low odour formation
- Excellent anti-aging properties
- UV stability
- Colour stability
Pilot® extender oils enable a long service life for the cured sealant - for us, this means a sustainable product, satisfied customers and convinced end users.
Pilot® extender oils and their properties
Product grades with low aromatic content:
|
Typical data |
Method |
Pilot 200H |
Pilot 250H |
Pilot 275H |
Pilot 300H |
Pilot 400H |
Pilot 500H |
Pilot 600H |
|
Appearance
|
Visual
|
Clear & colorless
|
Clear & colorless
|
Clear & colorless
|
Clear & colorless
|
Clear & colorless
|
Clear & colorless
|
Clear & colorless
|
|
Color (Saybolt)
|
ASTM D 156
|
30
|
30
|
30
|
30
|
30
|
30
|
30
|
|
Initial Boiling Point (IBP)
|
ASTM D86
|
220 °C
|
235 °C
|
250 °C
|
260 °C
|
280 °C
|
280 °C
|
310 °C
|
|
Final Boiling Point (FBP)
|
ASTM D86
|
243 °C
|
275 °C
|
295 °C
|
320 °C
|
320 °C
|
360 °C
|
360 °C
|
|
Density @ 15 °C
|
EN ISO 12185
|
820 kg/m3
|
820 kg/m3
|
820 kg/m3
|
820 kg/m3
|
820 kg/m3
|
820 kg/m3
|
820 kg/m3
|
|
Flash Point (PM)
|
EN ISO 2719
|
min. 88 °C
|
min. 100 °C
|
min. 110 °C
|
min. 110 °C
|
min. 130 °C
|
min. 130 °C
|
min. 140 °C
|
|
Kinematic Viscosity @ 40 °C
|
DIN 53015
|
1.9 mm²/s
|
2.5 mm²/s
|
3.0 mm²/s
|
4.5 mm²/s
|
4.5 mm²/s
|
5.5 mm²/s
|
6.5 mm²/s
|
|
Aromatics (UV)
|
HM-14-Labor
|
max. 2000 ppm
|
max. 1000 ppm
|
max. 1000 ppm
|
max. 1000 ppm
|
max. 1000 ppm
|
max. 1000 ppm
|
max. 1000 ppm
|
|
Pour Point
|
DIN ISO 3016
|
|
max. -40°C
|
max. -30°C
|
max. -20°C
|
max. -10°C
|
max. -5 °C
|
max. 5 °C
|
Product grades with medium aromatic content:
|
Typical data |
Method |
Pilot 140 | Pilot 150H | Pilot 295 SR |
|
Appearance
|
Visual
|
Clear & colorless | Clear & colorless | Clear & colorless |
|
Color (Saybolt)
|
ASTM D 156
|
24 | 24 | |
|
Initial Boiling Point (IBP)
|
ASTM D86
|
260 °C | 260 °C | 256 °C |
|
Final Boiling Point (FBP)
|
ASTM D86
|
330 °C | 320 °C | 296 °C |
|
Density @ 15 °C
|
EN ISO 12185
|
816 kg/m3 | 816 kg/m3 | 818 kg/m3 |
|
Flash Point (PM)
|
EN ISO 2719
|
min. 120 °C | min. 110 °C | min. 118 °C |
|
Kinematic Viscosity @ 40 °C
|
DIN 53015
|
4.32 mm²/s | 4.4 mm²/s | 3.0 mm²/s |
|
Aromatics (UV)
|
HM-14-Labor
|
5.4% v | 4.5% v | 9% v |
|
Pour Point
|
DIN ISO 3016
|
max. -6°C | max. -5°C | max. -33°C |
More information on our Pilot extender oils can be found in our product database.
To produce quality products such as our Pilot® extender oils, we rely on three strategies
1. Innovative technology
With our new hydrogenation plant at the Speyer site, we are able to produce our Pilot® extender oils for silicone sealants with extremely low aromatic content and thus offer our customers particularly high-quality and at the same time sustainable products.
2. Individual formulations
Together with you, we will find exactly the right Pilot® extender oil for your particular application. Benefit from our experience, expertise and technologies to produce tailor-made extender oils for silicone seals.
3. Personal customer focus
For us, strong partnerships and long-term business relationships are a reality. This is the only way we can achieve the best result together with you. This requires trust. Benefit from our personal 360° service.
Conclusion
Pilot® extender oils from Haltermann Carless fulfil important functions in silicone seals. High quality features such as UV-resistance and lowest aromatic content make the silicone sealant a long-lasting and thus sustainable product. With our individual service and our customised portfolio, we create the best conditions for your silicone sealants.
